Henrob Self-Pierce Riveting
Self-Pierce Riveting (SPR) Technology presents an ideal solution for joining metals or dissimilar materials, such as aluminum to steel or metals to composites. What sets SPR apart is its ability to eliminate the need for pre-drilled holes in the material before inserting the rivet. This innovative process yields significantly stronger and fatigue-resistant joints compared to spot welding, and can even be used in conjunction with adhesives. Embrace the cutting-edge advantages of SPR for seamless, durable, and versatile material joining in your projects.
"No holes, no fumes, no sparks and a cycle time of two seconds"
Products and Services
At Omnino, we offer an extensive selection of Self Pierce Rivets (SPR) catering to various industries. From manual units to large automated systems, our range includes tools and machines for all applications. Our experienced team can custom design and build an SPR system tailored precisely to your needs, or you can opt for one of our readily available machine designs.
We proudly support multiple manufacturing industries, including Grain Silos, Water Tanks, Road Signs, Steel Frame Housing, Caravans, Commercial Buildings, and more.
Contact us and discover the perfect SPR solution for your specific requirements.
Self-Pierce Riveting Process
Self-Pierce Riveting is a unique assembly process in which a semi-tubular rivet is driven through multiple layers of material to be joined.
The rivet then flares out under the influence of a special die, forming a strong joint between the layers of material.
What makes the SPR process unique? Unlike normal riveting, no hole is required in the material before the rivet is inserted…..
Self-Pierce Riveting Machines and Tools
Our design team will work with you to create the riveting system best suited to your application. Over the years Omnino has created many systems from small manual systems to large completely automated systems.
Examples of some of the more common systems are shown below, which are utilised in the manufacturing of grain silo's, water tank's, road signs, steel frame housing, caravan's and commercial building systems, in Australia and around the world.
​
Our Road Sign Machine is designed to rivet the aluminium or steel channel to the back of the road sign, leaving a flush surface for applying the reflective film.
Our 4RS Bridging Piece Machine automatically inserts four rivets at a time, with integrated touch screen and safety light curtain, making assembly of roof bridging pieces efficient.
Our 1RS Bridging Piece Machine is a manually operated machine inserting one rivet at a time, simplifying manufacturing needs.
Our Grain Silo Manufacturing Systems can rivet three rivets at a time, joining the vertical and horizontal joints efficiently.
Our hand operated machine, suspended by a counter balance and overhead jib, makes the assembly of steel frame housing efficient.
Our hand-operated machine offers flexible suspension options, either by a counterbalance and overhead jib or a gantry system, enabling efficient assembly of aluminum frames.
The Water Tank Machine features a 1050mm deep throat, allowing for both horizontal and vertical joining of corrugated steel for the manufacture of water tanks.
Our Box Beam Machine integrates an O Frame and Floating Dies to create strong joins in the manufacturing of Box Beams
Our Hydraulic Power Pack offers efficiency and a user-friendly interface. Offering the convenience of inbuilt remote access capability for easy diagnostics, ensuring effortless maintenance and monitoring.
